Stress, strain and the Young modulus

The Young modulus, tensile stress over tensile strain, is stiffness with the specimen's dimensions divided out, so it belongs to the material and does not change when the material is reshaped. Strain has no unit, so the modulus is measured in pascals like the stress. The gradient of the straight part of a stress-strain graph gives it, and the curves for ductile, brittle and polymeric materials differ beyond the straight part.

Watch on YouTube (opens in a new tab)

Year 12AQA 3.4.2.2 CIE 6.1.5, 6.1.6 OCR A 3.4.2(c), 3.4.2(d)(i), 3.4.2(d)(ii), 3.4.2(e)EDEXCEL 54, 56, 57

Builds on Density and Hooke's law and Uncertainty and error.

IN THIS TOPIC

Define tensile stress and tensile strain, and give the unit of each.
Use the Young modulus as stress over strain, and assemble the $FL/A\Delta L$ form yourself when you need it.
Take E from the gradient of the straight part of a stress-strain graph.
Read yield, breaking stress and brittle failure off a stress-strain curve, and describe one method of measuring E for a wire.
Tell the ductile, brittle and polymeric stress-strain shapes apart, and explain why rubber stiffens as it stretches and loses energy round its hysteresis loop.

COMMON MISCONCEPTION

The spring constant tells you how stiff the material is.

The spring constant k describes one particular object: change its length or thickness and k changes. The Young modulus is stress over strain, which cancels the geometry and characterises the material itself.

Why the spring constant does not describe a material

The spring constant describes one particular object. Take the same steel and draw it into a thicker wire, and k rises; make the wire longer, and k falls. The steel has not changed, only its shape, so k does not describe the material.

To reach the material itself, divide the geometry out. Spread the force over the cross-section, then compare the extension against the length being stretched.

\text{tensile stress} = \frac{F}{A}

IN THE AQA DATA BOOKLET

\text{tensile strain} = \frac{\Delta L}{L}

IN THE AQA DATA BOOKLET

Stress is measured in N m⁻², the pascal, the same unit as pressure and for the same reason. Strain is a length over a length, so it has no units at all. Small strains often get quoted as percentages, which is a convenience and not a unit.

The Young modulus

For a given material, stress and strain stay proportional while the deformation is modest, and their ratio is the Young modulus.

E = \frac{\text{tensile stress}}{\text{tensile strain}}

IN THE AQA DATA BOOKLET

Substitute the two definitions above and the working form follows, $E = FL/(A\Delta L)$ . That combined version is not printed in the booklet, but all three of its ingredients are, so it can be rebuilt from them rather than memorised as a fourth formula.

A wire hangs from a mount with original length L marked, a short highlighted extension delta L beneath it, and a load F pulling down; an inset circle shows the wire's cross-section of area A. — FIG. 1The four quantities the Young modulus combines: the load F, the cross-sectional area A, the original length L and the extension ΔL.

E is measured in pascals, and for solids the numbers are enormous. Steel sits near $2 \times 10^{11}$ Pa, so even a very large stress produces only a small strain. A large Young modulus is what the phrase “stiff material” actually means, and unlike k it survives any reshaping of the sample.

A straight stress-strain line with a dashed gradient triangle drawn beneath it: the rise over the run, delta stress over delta strain, is the Young modulus. — FIG. 2On the linear part of a stress-strain graph, the gradient is the Young modulus.

WORKED EXAMPLE

Stress, strain, then the stretch

A brass wire (E = 1.2 × 10¹¹ Pa) of diameter 0.60 mm and length 2.5 m carries a 60 N load. Find the stress, the strain, and the extension.

Area first. A = πd²/4 = π × (6.0 × 10⁻⁴)²/4 = 2.83 × 10⁻⁷ m².

Then the stress, σ = F/A = 60/(2.83 × 10⁻⁷) = 2.1 × 10⁸ Pa.

Strain follows from ε = σ/E = 2.1 × 10⁸/(1.2 × 10¹¹) = 1.8 × 10⁻³, a bare number with no unit.

Finally ΔL = εL = 1.8 × 10⁻³ × 2.5 = 4.4 mm. Because the extension is only a few millimetres in a 2.5 m wire, the measurement needs a marker read against a fixed ruler.

Reading stress-strain curves

A full stress-strain curve characterises a material's tensile behaviour under the conditions of the test, and you are expected to read its landmarks.

Two curves from the origin: a ductile material runs straight, yields, flattens through a plastic region and fractures at large strain; a brittle material climbs a steeper straight line and snaps with no plastic region at all. — FIG. 3A ductile material yields, stretches through a long plastic region and fractures at large strain; a brittle one climbs its straight line and snaps with little or no plastic region.

A ductile material such as copper runs straight, passes its yield point, then stretches enormously at almost constant stress through its plastic region before it fractures. The maximum stress the specimen withstands is its ultimate tensile stress, which A-level papers usually call the breaking stress; strictly, a ductile specimen necks after that maximum and finally fractures at a lower engineering stress. A brittle material such as glass or cast iron shows little or no plastic deformation. It follows its straight line and fractures with little prior deformation to give warning of failure.

A third shape completes the set. A polymeric material such as rubber or polythene is built from long molecular chains, tangled together rather than locked into a lattice, and its curve resembles neither of the other two. Stretch rubber and at first the chains merely uncoil, which takes very little stress and gives an enormous strain. Once they are pulled straight, the bonds themselves have to stretch, and the curve stiffens sharply. So a rubber graph starts shallow and steepens, the opposite way round from a metal, and it runs to strains of several hundred per cent where a steel wire has long since fractured.

Stress-strain curves for a brittle, a ductile and a polymeric material, each on its own strain scale — FIG. 4The three characteristic shapes, each drawn on its own strain scale, because rubber outruns steel by three orders of magnitude. Brittle snaps at the end of its straight line, ductile yields and flows, and polymeric starts shallow and stiffens, its unloading curve returning below the loading one.

Two things follow from that shape. Rubber has no single Young modulus, because the gradient changes all the way along and never settles, so rubber does not obey Hooke's law over the range drawn. Yet the deformation stays elastic: let go and the sample returns to its original length. Elastic behaviour and proportionality are separate properties: rubber is elastic but not Hookean.

Unloading rubber traces a lower curve than loading did, and the loop enclosed between the two is called hysteresis. Its area is work that went in and came back out as heat instead of as recovered strain energy, which is why a squash ball warms through a rally and why a tyre run hard gets hot. Polythene shows the other polymeric behaviour worth knowing: it stretches easily at low stress and stays stretched, deforming plastically where rubber recovers.

GUIDED PRACTICE

Reading E off a graph

On a stress-strain graph, a material's straight portion passes through stress 1.5 × 10⁸ Pa at strain 7.5 × 10⁻⁴. Find its Young modulus from the gradient.

Show the working

E = gradient = σ/ε = 1.5 × 10⁸/(7.5 × 10⁻⁴) = 2.0 × 10¹¹ Pa.

That is steel's value. Only the straight portion counts, because past the limit of proportionality the ratio drifts from point to point and stops being a constant of the material.

INDEPENDENT PRACTICE

Energy stored in every cubic metre

For the same material at the same point (σ = 1.5 × 10⁸ Pa, ε = 7.5 × 10⁻⁴), find the elastic energy stored per unit volume, using the area under the stress-strain line.

Show the working

The area under the straight line is a triangle, ½σε = ½ × 1.5 × 10⁸ × 7.5 × 10⁻⁴ = 5.6 × 10⁴ J m⁻³.

The units land correctly because a pascal is already a joule per cubic metre. Multiply N m⁻² by a strain that carries no unit and energy per volume is what you are left with. About 5.6 × 10⁴ J is stored in each cubic metre of the loaded steel.

A simple measurement

Your specification requires one simple method. Clamp a long, thin wire of the test material at one end of a bench, run it over a pulley at the far end, and hang masses from it. Measure the original length L from clamp to a reference marker with a metre rule, the diameter with a micrometer at several places along the wire, averaging and using $A = \pi d^{2}/4$ , and the extension ΔL by how far the marker moves against a fixed ruler as loads are added.

A long horizontal wire runs from a bench clamp over a pulley to hanging masses. A small marker on the wire sits against a ruler, and the original length L is measured from the clamp to the marker. — FIG. 5The simple method: a long clamped wire, a marker read against a ruler, a pulley and hanging masses.

Plot stress against strain and take the gradient of the straight region. The wire is long and thin for two reasons: a small cross-sectional area gives a large stress from bench-sized loads, and a long wire gives an extension large enough to measure with a small percentage uncertainty. The micrometer's resolution sets the uncertainty in d, and the power rule doubles that percentage on the way into A.

ASSESSMENT FOCUS

Strain has no units; state this explicitly. A strain that comes out in metres means the lengths were never divided.
The area comes from the diameter, $A = \pi d^{2}/4$ . Using the diameter where the radius is needed, or halving it twice, both give the wrong area.
“Why long and thin?” has a precise answer. Both choices enlarge ΔL, and a larger ΔL carries a smaller percentage uncertainty.
Take the Young modulus from the gradient of the straight region only. Past the limit of proportionality the ratio is not E any more.
Brittle on a graph means no plastic region. The material fractures at, or barely beyond, the end of its straight line.
Polymeric on a graph means the gradient rises with strain, and the unloading curve sits below the loading one. Name the enclosed loop as hysteresis and the area as energy released as heat. OCR asks for all three shapes together; the other boards examine only ductile and brittle.
Rubber is elastic but not Hookean. Returning to its original length shows elastic behaviour, not proportionality, and there is no single Young modulus to quote for it.
Stress, strain and E as their ratio are all printed. $FL/A\Delta L$ is not, so build it from the three that are.

CHECK YOURSELF

A wire of length 1.8 m and diameter 0.40 mm extends by 1.8 mm under a load of 25 N. Calculate the Young modulus of the material.

Show a hint

Find the area from the diameter first, working in metres.

Show the answer

Start with the area. $A = \pi d^{2}/4$ = π × (0.40 × 10⁻³)² / 4 = $1.26 \times 10^{−7}$ m².

Stress is $F/A$ = 25 / (1.26 × 10⁻⁷) = $1.99 \times 10^{8}$ Pa, and strain is $\Delta L / L$ = 0.0018 / 1.8 = $1.0 \times 10^{−3}$ .

Divide one by the other. $E$ = 1.99 × 10⁸ / (1.0 × 10⁻³) = $2.0 \times 10^{11}$ Pa, the standard value for steel. A strain of one part in a thousand under a 25 N load is typical for a metal wire of this size.

k describes the object.

E describes the material.

Reshape the sample and only one of them changes.

WORKBOOK

Printable practice for this topic: original exam-style questions with room to work, and a fully worked answer book. Free to use; please do not redistribute or sell.

19 questions on this topicAnswer them one at a time and mark yourself against the mark scheme.Practise this topic

Or read them with their mark schemes on the stress, strain and the Young modulus questions page.

13 flashcards on this topicDefinitions, off-sheet equations and a spot-the-error card, scheduled by spaced repetition in your browser.Revise with flashcards

WHERE TO GO NEXT

Required practical 4: the Young modulus of a wire puts this topic in the lab, and the written papers ask about it.
Gradients and areas under graphs is the maths this lesson leans on, worked through step by step.
Combining uncertainties is the maths this lesson leans on, worked through step by step.

USED LATER IN

Resistivity and temperature
